Overview Package Size 26.00cm * 20.00cm * 19.00cm Package Gross Weight 0.500kg Product Description Through-wall terminal;
Overview
Basic Info.
Model NO. TW100-70/25-05
Species Terminal
Production Process Injection Molding
Shape Rectangular
Interface Type AC/DC
Certification UL, TUV
Rated Current 50A
Standard Packing 27PCS/Carton
Rated Impulse Voltage 6000V
Rated Voltage 600V
Transport Package Plastic Bag + Carton
Specification 365g/PCS
Trademark Exceedconn
Origin China
HS Code 8536300000
Production Capacity 80000 Pieces/Month
Packaging & Delivery
Package Size 26.00cm * 20.00cm * 19.00cm Package Gross Weight 0.500kg
Product Description

Product Description

Through-wall terminal plug-in 5 pins 110A pluggable panel terminal block

Electrical Performance
Rated Voltage600V AC
Rated Impulse Voltage6000V
Rated Current50A
Contact Resistance≤10mΩ
Insulation Resistance≥500MΩ
Mechanical Capacity
Rated Screw TorqueM5 5 N.m - 8 N.m
M3 0.8N.m - 1N.m
Cable Gauge25-50mm² Copper Conductor
Operational Environment
Ambient Temperature-40ºC~+105ºC
Relative Humidity5%~95%
Flammability Class(Insulator)V-0
Material
PlasticPC+PBT/PBT
ConductorCopper Alloy with Ni Plating
Connecting ScrewStainless Steel

Company Profile

Exceedconn is committed to provide lighting system connection solutions, products R&D, manufacturing and OEM service. The products are widely used in the fields of city lighting, landscape, solar energy and industrial control etc. Main customers are industry leading enterprises.With many years development, Exceedconn owns a professional and strong technical team. We can provide individualized connection solutions for different customer in different fields. Company has more than 50 patents in connection solutions till now.Adhering to the "rigorous, responsibility, cooperation" business philosophy, Exceedconn provides customer high quality products and service.Exceedconn---Your strong supports on connection solutions.

Through-Wall Terminal Plug-in 5 Pins 110A Pluggable Panel Terminal Block

Through-Wall Terminal Plug-in 5 Pins 110A Pluggable Panel Terminal Block

Through-Wall Terminal Plug-in 5 Pins 110A Pluggable Panel Terminal Block

Certifications

Through-Wall Terminal Plug-in 5 Pins 110A Pluggable Panel Terminal Block

Packaging & Shipping

Through-Wall Terminal Plug-in 5 Pins 110A Pluggable Panel Terminal Block

FAQ

Q: Can you offer samples?
A: We can supply the free sample with freight collect.

Q: Can I visit your factory?
A: Yes,It will be better for us face to face to talk about the project.And I am sure you will be confident in us after you visit our factory.

Q: What's your after-sales service?
A: We provide you with technical support and can help you to solve your customers' problem.

Q: Do you have a catalogue? A: Yes, we have product catalogue.Please contact us online or send an Email for catalogue.
